Tractor Mounted PTO Drive Fixed Hammer Mulchers.  sevenlogo

Capable of Producing Classe I / Category I Mulch*

TTFK Mulcher for tractors 100-180 HP

twfk

FRAME

  • Welded mainframe with double layer of high strength cold formed steel.
  • Specially designed front end for facilitating the input of material.
  • Front quadruple chain curtains + 1 extra curtain.
  • Cat. II with incorporated quick hitch coupling to tractor.
  • Hydraulic rear hood made of high strength steel (for facilitating the material entrance and obtaining the best finish in mulching).
  • Sidestep system in frame sides for overcoming obstacles.
  • Height adjustable rounded side skids (2 positions).
  • Protected hydraulic hose connections and lubrication points.

ROTOR / TRANSMISSION

  • Rotor assembled with fixed hammers.
  • DuoBoltTM hammer assembly.
  • 10 XPB drive belts with ESB system.
  • Gearbox with built-in freewheel and input to 1000rpm (1-3/4” Z6)
  • Rotor Assembled with self-aligning spherical roller bearings.
  • Reinforced PTO shaft.

CUTTING TOOLS

  • Hammers with 2 carbide tips.
  • Hammer holders S08 type welded to rotor with double helicoidal arrangement.

TTFZ Mulcher for tractors 170-250 HP

tfz-diant

FRAME

  • Welded mainframe with double layer of high strength cold formed steel.
  • Specially designed front end for facilitating the input of material.
  • Front quadruple chain curtains + 1 extra curtain.
  • Cat. II with incorporated quick hitch coupling to tractor.
  • Hydraulic rear hood made of high strength steel (for facilitating the material entrance and obtaining the best finish in mulching).
  • Sidestep system in frame sides for overcoming obstacles.
  • Height adjustable rounded side skids (3 positions).
  • Protected hydraulic hose connections and lubrication points.

ROTOR / TRANSMISSION

  • Rotor assembled with fixed hammers.
  • DuoBoltTM hammer assembly.
  • 12 XPB drive belts with ESB system.
  • Gearbox with built-in freewheel and input to 1000rpm (1-3/4” Z6)
  • Rotor Assembled with self-aligning spherical roller bearings.
  • Reinforced PTO shaft.

CUTTING TOOLS

  • Hammers with 2 carbide tips.
  • Hammer holders S02 type welded to rotor with double helicoidal arrangement.

TTFT Mulcher for tractors 200-360 HP

twwf

FRAME

  • Welded mainframe with double layer of high strength cold formed steel.
  • Specially designed front end for facilitating the input of material.
  • Front quadruple chain curtains + 1 extra curtain.
  • Cat. II with incorporated quick hitch coupling to tractor.
  • Hydraulic rear hood made of high strength steel (for facilitating the material entrance and obtaining the best finish in mulching).
  • Sidestep system in frame sides for overcoming obstacles.
  • Height adjustable rounded side skids (3 positions).
  • Protected hydraulic hose connections and lubrication points.

ROTOR / TRANSMISSION

  • Rotor assembled with fixed hammers.
  • DuoBoltTM hammer assembly.
  • 12 XPB drive belts with ESB system.
  • Gearbox with built-in freewheel and input to 1000rpm (1-3/4” Z6)
  • Rotor Assembled with self-aligning spherical roller bearings.
  • Reinforced PTO shaft.

CUTTING TOOLS

  • Hammers with 2 carbide tips.
  • Hammer holders S02 type welded to rotor with double helicoidal arrangement.

ttf1



ttf3
ttf4

Greatest density of carbide hammers in the industry. Unique efficient, spiral cutting pattern.

Lubrication points protected and well marked.

Twin double chain curtain (4 rows).

Adjustable, 20mm HARDOX® steel skids.

gearbox-ttwf

Oscillating gearbox maintains the same angle of the PTO shaft in any position.

The Seven TT-Series mulchers feature oversize roller bearings on the main shaft, a welded body of DOMEX® steel and skid pads made from HARDOX® steel giving the mulcher a long and productive life in the toughest of conditions. A hydraulically controlled gate ensures safe operation: gate is open for cutting and closed for mulching.



Self-aligning roller bearings in rotor for assuming/ absorbing possible misalignments during operation. Replaceable shafts in rotor, bolted with special safety system.



An ecological solution: mulching has proven environmental and economic advantages over the use of chemical sprays to control brush growth. Mulching eliminates the potential danger to the soil and water table.

tt-hydraulicbelt

High performance drive belts or poly chain

hammersx

Easy to replace, bolt on carbide tipped mulcher teeth with the DuoBoltTM locking system.

counterblades

Replaceable counter blades

welded-main-frame
  • Welded mainframe with double layer of high strength cold forming DOMEX® S700 steel. Enclosed body system prevents debris from entering the internal components.
  • VOITH hydraulic couplings are optional for soft and progressive start and shutdown in overloads. Special cooling system made in Germany.
hammerdiagramttz

With the two stage hammer the central carbide point penetrates wood easier, the wider second carbide blade increases mulching action.

Replaceable 45mm wide hammers made of hard alloys with carbide wear points and DuoBoltTM mounting (F03 Hammers on center rotor, F04 hammer on side). The Model TTFT features unique “Two stage carbide hammers”. These 55mm wide F05 and F06 hammers have two separate levels of carbide cutting surfaces and a reinforced forged steel anvil which attaches the hammer to the rotor. Research has found that when mulching with machines over 200 HP, the mulching properties change. This is why on “Seven” mulchers the hammers used on a 100 HP mulcher are not the same hammers used on the larger models.

The benefit of the two stage hammer is: increased mulching speed, with lower fuel consumption.

ttwk-225Mulching has proven environmental and economic advantages over the use of chemical sprays to control brush growth. Mulching eliminates the potential danger to the soil and water table.hammer

  • The SEVEMTM TTW mulchers feature a large diameter rotor with a close ratio hammer configuration, resulting in long hammer life, increased grinding capacity and the production of fine “Classe I/Category I mulch”*. A fine mulch gives good ground cover and returns to nature quickly.
  • The SEVENTM TTW mulchers feature a welded body of DOMEX® steel and skid pads made from HARDOX® steel giving the mulcher a long and productive life in the toughest of conditions.
  • A hydraulically controlled gate ensures safe operation: gate is open for cutting and closed for mulching.
  • The machine incorporates replaceable carbide tipped hammers, with the DuoBoltTM locking system, made of special alloys and hard metal designed to provide excellent material penetration and long life.
  • Large diameter rotor thickness. Electronically balanced. Assembled with self aligning spherical roller bearings with conical inner rings.
  • High performance belts. Replaceable front and rear chain curtains.
  • Available with optional hydraulic guard frame incorporating retractable raker teeth.

Nine SEVENTM TTW Mulchers to Choose from:

TTmuchersptospecs

** The weight of the machines is approximate, it refers to the standard version with any options and it may vary. The information and images contained in this document are to be considered reference values. The St. George Company reserves the right to make changes without notification.
SEVEN® is a registered trademark of The St. George Company. © The St. George Company, 2015

What is Classe 1/Category 1 Mulch?

The SEVENTM line of mulchers are engineered to producing fine mulch (Classe 1/Category

1). This fine mulch decomposes and returns to the soil much more quickly resulting in maximum ecological benefits often eliminating the need to remove debris from the site.



Most mulchers on the market today are capable of reducing brush to slash (Classe 3/ Category 3) or large chips (Classe 2/Category 2). In time, these larger pieces of debris will decompose and return to the soil.

Classe 1 / Category 1 Mulch
